01、 Support basket
Durable electrolytic polishing SS316 support basket (included in the container) makes it possible for filter bag - HAYFLOW components to bear the differential pressure up to 3.5 BAR. There are various sizes of support basket, which is suitable for all INOCO bag filter. Support basket with special material such as hastelloy (HASTORY) / E - CTFE (HALAR) coating is optional. Standard support basket with adapter can be installed in other kinds of filters.

02、 LOFNETIC magnet components
During filtering, one / more magnetic bars with supporting frame will be put inside the filter bag, which effectively sucks out mixed iron particles, avoids accumulated in the filter material, so that lengthen the service life of filter bag. When using a relatively coarse filter bag, it can also suck the slightly less iron powder out. Magnetic bar component has # 01 - # 02 two sizes. It is available to use one / two magnetic bars with SS316 shell.

03、 Filter bag support frame
For safety reasons, filter should use the support frame. It prevents the filter bag move up  down due to the instability of pressure, , ensures the filter bag fitting with the support basket, avoids the folding of the filter material , makes full use of the filter area. Support frames are more needed for ACCUGAFTM, PROGAFTM , LOFCLEARTM 500 series filter bags. New-design collar ring makes the support frame remain in the filter bag. Filter bag support frame has # 01 、 # 02 two sizes.

04、 Support leg component
Height adjustable support leg has #01 、#02 two sizes. It is the standard device of TOPLINE vessel. ECOLINE, FLOWLINE, SIDELINE other filters can select it separately. Wall type bracket can also be selected.

05、 Hollow ball
When filtering, the hollow ball floats inside the filter bag, reduces the fluid left behind the filter bag  the product loss, makes it easier to change the filter bag no longer required of expensive compressed air drainage system. New-design collar ring keeps hollow ball stable in the filter bag. The material is SS316, the max differential pressure is 16 bar, there are # 01 、#02 two sizes

06、 Diverse components
There is 90 degree elbow, flanged reducer, Tee  flanged Cross in INOCO standard SS316 pipe fittings, which makes it easy to change from FLOWLINE, SIDELINE - TOPLINE 01 、 02 filter to DUOLINE /MODULINE.

07、 Open system connector
Used for gravity filter system with SNAP - RING steel ring filter bag, 1.5 "BSP connection, material has stainless steel  polypropylene, is applicable to the condition of pressure below 0.15 MPA (1.5 Bar).

08、Sealing washer
INOCO metal container is equipped with standard BUNA N - sealing ring, plastic container is with FPM o-ring. There are also other materials such as EPDM, fluorine rubber (FPM), FPM with PTFE lining / silicone rubber for option. They have different ageing resistance , heat resistance properties, are suitable for different applications.

09、 Filter mesh
A series of SS316 filter meshes can change the bag filtering into mesh type filtering. There are 1#, 2#, 3#，4# four kinds of sizes, 25, 50, 100, 150, 250, 400, 800 micron ratings.

10、 Other
INOCO always prepares for pressure gauge, vent valve, bolt, V - CLAMP clip, T bolt, butterfly valve / ball valve - other accessories for option, which can be used for all kinds of INOCO filters.

11、 Filter bag pressure ring
Various series of containers such as ECOLINE, SIDELINE, FLOWLINE, POLYLINE 、MAXILINE all have different filter bag pressure ring (included in the container). It will press the filter bag tightly in the container.

NOCO representative applications of high performance filter bags

		Auto Industry Pre-treatment ,electrophoresis paint, finish machine varnish filtration; Primer paint, paint loop line filter; Parts cleaning fluid ,filling mixture, lubricating, metal working fluid and filtration before pump.
		Chemical Catalyst recovery: remove scale in the water pipe; Liquid clarification; Filter acid and alkali solvent; Filter emulsion and dispersion; Colloid in filter resin.In the fine chemical industry, removing activated carbon or catalyst is a typical example of high requirements,INOCO filter bags can meet the stringent requirements of these applications, high filtration efficiency while long service life and reliable.
		Electronic Chip production process, electronic etching groove; Actinic polishing, high purity water filter cartridge as a pre-filter for multiple modes of filtration to extend its service life, cleaning is one of the key factors in achieving success in the electronics industry, because chemicals require frequent filtration of extremely low particle content, INOCO's filter bags demonstrate the required efficiency and consistency.
		Food and beverage Beer, wine and whisky essence filtered; Remove particles from cooking oil; Remove the carbon ink from the fiber and the glue from the gelatin; Clarification of syrup concentrate and corn syrup; In addition to meeting the various and specific requirements for these applications, INOCO filter bags for starchy milk and beverages meet FDA and EEC standards for the food industry
		Metal processing Hydraulic oil filtration; Pre-treatment filtration; Recovery of precious metals; Metal processing and filling mixtures parts cleaning machines use our filter bags to reduce residual impurities on parts.
		Petrochemical Filter lubricating oil fuel additive; Oil recovery; Amine liquor glycol liquor filtration; Gas purification process; Distillation and fractionation processes; Machine wash amine; Offshore filtration station; Drilling oil and injection.
		Paint and enamel Remove the clumps of paint; Solvent filtration; Remove impurities formed in storage; Packaging line and mixing line filtration, monomer purification
		Pharmacy Recovery of expensive active materials; Recovery of catalyst; Remove activated carbon; Gelatin hormone vitamin concentrator; Filtration of herbs; Remove plasma protein; Filter brine.
		Resin plastic ink and paint Oil and polymer filtration; Dispersion polymer production; Can coating with resin plastic synthetic paper coating high purity ink-jet filter.
		Water treatment Well water filtration; Water treatment plants; Desilting; Remove scale from water pipes; It's too early to remove sand and debris from the sea; Recovery of ion exchange resin; Remove calcium crystals; Chemicals for filtration wastewater treatment; The application of dust in the filter cooling system in the surface water filtration is mainly based on the filter element in the past, but today, the high efficiency and longevity of INOCO's high performance filter bag is a more cost-effective choice.
